BV1-UGF8-T10-316
BV1-UGF8-T10-316
| Attribute | Ball Valves |
| Body Material | 316 Stainless Steel |
| Connection 1 Size | 1/2 in. |
| Connection 1 Type |
Nut + Gasket + Fractional Tube Bulge Nipple |
| Connection 2 Size | 1/2 in. |
| Connection 2 Type |
Nut + Gasket + Fractional Tube Bulge Nipple |
| Seat Material | PTFE |
| CV Maximum | 3 |
| Orifice | 0.406 in. /10.3 mm |
| Handle Color | Black |
| Flow Pattern | 2-Way, Straight |
| Temperature Rating | -65℉ to 450℉ (-54℃ to 232℃) |
| Working Pressure Rating | Max 6000 PSIG (413 bar) |
| Testing | Gas Pressure Test |
| Cleaning Process | Standard Cleaning and Packaging (CP-01) |
